The LIS series pneumatic horizontal shock tester is suitable for products that cannot be tested by changing the direction of
placement (changing the direction of the impact force by 90° into a vertical shock direction), for example, some slender products are launched in the longitudinal direction and at the simulated level. For tests, etc., it is necessary to use a horizontal shock test rig to complete the shock test.
APPLICATION
The equipment is used to detect early faults, simulate actual working condition assessment and structural strength test.
The product has a wide range of applications, wide application range, and remarkable and reliable test results.
model | LIS50 | LIS100 | LIS200 | LIS400 | LIS600 | LIS1000 | LIS1800 | |||||
Shock test parameters | ||||||||||||
specified load (kg) | 50 | 100 | 200 | 400 | 600 | 1000 | 1500 | |||||
Table size(mm*mm) | 500*700 | 500*700 | 500*900 | 600*1000 | 700*1000 | 800*1300 | 1800*1800 | |||||
Peak impulse acceleration | Half sinusoidal waveform(m/s2) | 15-1000 | 15-1000 | 15-800 | 15-600 | 15-500 | 15-400 | 15-800 | ||||
Pulse duration | Half sinusoidal waveform(ms) | 1-40 | 2-40 | 2.5-40 | 3-40 | |||||||
Impact distance (mm) | 650 | 600 | 550 | 500 | ||||||||
Maximum speed change (No load)(m/s) | 7.8 | 7.8 | 7.2 | 7.2 | 7.0 | 6.8 | 4.0 | |||||
Maximum speed change (No load)(m/s) | 7.0 | 7.0 | 6.5 | 6.5 | 6.3 | 6.0 | 3.5 | |||||
Crash test parameters | ||||||||||||
Collision pulse waveform | Half sine wave | |||||||||||
Collision peak acceleration (m/s2) | 15-80 | |||||||||||
Collision pulse duration (ms) | 1-40 | 1-40 | 2-40 | 2.5-40 | 3-40 | |||||||
Collision distance automatic adjustment range | 1-80 | 1-60 | 1-40 | |||||||||
Maximum speed change (m/s) | 2.3 | 2.3 | 2.1 | 2.0 | 1.8 | 1.6 | (not) | |||||
Configuration air source | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | |||||
Configure the air source (collision) (m3/min/8kg/cm2) | 1.6 | 2.0 | 3.0 | 3.2 | 4.0 | (not) | ||||||
Whether to configure the gas tank | (not) | (not) | (not) | Need 3m3 gas storage tank | Need 3m3 gas storage tank | Need 3m3 gas storage tank | Need 3m3 gas storage tank | |||||
Table weight(kg) | 2800 | 2800 | 3260 | 3800 | 4900 | 5800 | 8500 | |||||
(L*W*H)(mm) Dimensions | 2750*820*710 | 2750*820*710 | 2950*820*710 | 3210*920*710 | 3210*1020*710 | 3510*1120*710 | 3740*2100*915 | |||||
Control System | ASK01 | |||||||||||
measuring system | MIS02 | |||||||||||
Platform power requirements | 220V±10%， (Simple Phase) AC，50Hz，2kVA | |||||||||||
Air compressor power requirements | 380V±10%，(Three phase) AC，50Hz | |||||||||||
Air compressor power (kVA) | 11 | 15 | 15 | 22 | 22 | 30 | 30 | |||||
Temperature range | 0℃-40℃ | |||||||||||
Humidity | ≤90%(25℃) No condensation | |||||||||||
Applicable standard | GB/T2423.5，GB/T2323.6，IEC 68-2-29 | |||||||||||
